Mars Global Surveyor
Mars Orbiter Camera

Mars Orbiter Camera (MOC) High Resolution Images

SUV Tracks On Mars?
The `Devil' Is In The Details



Mars Global Surveyor Mars Orbiter Camera Release:          MOC2-60a, -60b, -60c
Mars Global Surveyor Mars Orbiter Camera Image ID:         578078578.26403
							   P264-03

(A)
746 KByte GIF image

(A) Context for MOC image 26403. The MOC image subframe shown in (B) and (C), below, was shrunk to fit the above context frame. The arrow points to the location of the MOC image. The large crater at the left center of the picture is about 80 kilometers (50 miles) across. The base map is a portion of Viking 1 orbiter image 494a50. The original resolution of 494a50 was 329 meters (1,079 feet) per pixel--it was the highest resolution image available for this location until the MOC image was acquired in April 1998. This is a mercator projection centered at 15.4° N, 311.6° W in eastern Arabia Terra. North us up, illumination is from the left.

(B)
189 KByte GIF image

(B) MOC image 26403 subframe, shown at full resolution of 13.8 meters (45 feet) per pixel. Image covers an area that is 7.7 by 10.1 kilometers (4.8 x 6.3 miles) in size. North is approximately up, illumination is from the lower right.

(C)
369 KByte GIF image

(C) Enhanced version of the same MOC image 26403 subframe, shown in (B). Picture is seen here at full resolution of 13.8 meters (45 feet) per pixel. Arrows indicate two dark lineations, each about 2-3 pixels wide. Image covers an area that is 7.7 by 10.1 kilometers (4.8 x 6.3 miles) in size. North is approximately up, illumination is from the lower right.

You may need to adjust the images for the gamma of your monitor to insure proper viewing.

Note: This MOC image is made available in order to share with the public the excitement of new discoveries being made via the Mars Global Surveyor spacecraft. The image may be reproduced only if the image is credited to "Malin Space Science Systems/NASA". Release of this image does not constitute a release of scientific data. The image and its caption should not be referenced in the scientific literature. Full data releases to the scientific community are scheduled by the Mars Global Surveyor Project and NASA Planetary Data System. Typically, data will be released after a 6 month calibration and validation period.

Click Here for more information on MGS data release and archiving plans.

 CAPTION

Sport Utility Vehicles (SUVs) on Mars? Imagine the MOC imaging team's surprise on the morning of April 27, 1998, as the latest images came in from the "Red Planet."

A picture taken by the camera on Mars Global Surveyor just one day earlier showed several thin, dark lines that--at first glance--looked like pathways blazed by off-road sport utility vehicles. Who's been driving around on Mars?

The MOC image in question--#26403--was obtained around 10:22 a.m. PDT on April 26, 1998, during Mars Global Surveyor's 264th orbit. Located in eastern Arabia Terra near 16.5° N latitude, 311.4° W longitude, the image showed a number of natural features--small craters formed by meteor impact, several buttes and mesas left by erosion of the surrounding terrain, small dunes and drifts, and a mantle of dust that varies in thickness from place to place. But the new picture also showed two dark lines--each varying in width up to about 15 meters (49 feet)--that extended several kilometers/miles across the image.

Lines like these have been seen before on Mars. They are most likely the result of dust devils--columnar vortices of wind that move across the landscape, pick up dust, and look somewhat like miniature tornadoes. Dust devils are a common occurrence in dry and desert landscapes on Earth as well as Mars. They form when the ground heats up during the day, warming the air immediately above the surface. As pockets of warm air rise and interfere with one another, they create horizontal pressure variations that, combined with other meteorological winds, cause the upward moving air to spin. As the spinning column of air moves across the surface, it occasionally encounters dust on the surface, which it can suck upward. This dust rises into the spinning air, giving the appearance of a tornado-like column that moves across the landscape. As the column of air moves, its ability to pick up dust varies--sometimes they hold a lot of dust and are nearly opaque; sometimes you cannot even see them. Dust-devils rarely last long, since their very motion changes the conditions that allowed them to form in the first place.

Mars Pathfinder detected the passage of several dust devils during its 83 days of operation on Mars in 1997. Mariner 9 and the Viking landers and orbiters of the 1970s also found evidence that dust devils occur on Mars; indeed, some Viking Orbiter images actually show dust devil clouds. MOC image 26403 is the latest entry in the body of evidence for the work of wind in the modern martian environment. The MOC Science Team is continuing to study these and other streaks caused by wind interacting with the martian surface.



Malin Space Science Systems and the California Institute of Technology built the MOC using spare hardware from the Mars Observer mission. MSSS operates the camera from its facilities in San Diego, CA. The Jet Propulsion Laboratory's Mars Surveyor Operations Project operates the Mars Global Surveyor spacecraft with its industrial partner, Lockheed Martin Astronautics, from facilities in Pasadena, CA and Denver, CO.
