IKI RAN Radar Image Collection
Oceanic phenomena
/ Upwelling
Preview/
Location map
|
Image name
|
ERSC0010290152
|
| Platform/Sensor |
ERS-2/SAR |
| Flight altitude/speed |
785 km/6.8 km/s |
| Image partition |
No
|
| Wavelength(s)/Frequency(ies)/Band(s) |
0.057 /5.3/C |
| Polarization(s) |
VV |
| Incidence angle(s) |
23° |
| Calibration |
Preview image: black is lowest NRCS, white is highest NRCS
Full images: PRI format |
| Date/Time |
29.10.00 / 01:52 |
| Area |
Northwestern Japan Sea, Primorye coast |
| Coordinates |
43.289°N, 133.413°E, 43.103°N, 134.6°E
42.387°N, 133.154°E, 42.202°N, 134.323°E |
| Surface geometry |
100x102 km |
| Other signatures seen in the image |
None from the list of interest |
Supplementary information
AVHRR NOAA
Source image :
image size: 8000*8200; pixel = 16 bits; pixel size: 12.5 x 12.5;
file size: 128 Mb
Contact: Leonid Mitnik , Vyacheslav Dubina
References:
L.Mitnik, V.Dubina, Satellite SAR characterization of oceanic dynamic features in the Japan/East Sea // PICES-XI, Qingdao, China, 18-26 October, 2002, submitted.
