| Image name |
sirclx9404112131 |
|
Platform/Sensor |
SIR-C / X-SAR |
| Flight altitude/speed |
225 km / 7.8 km/s |
| Image partition |
4 fragments:L-VV, L-HH, L-HV, X-VV
|
| Wavelength(s)/Frequency(ies)/Band(s) |
L band: 1.25 GHz / 0.24 m; X band: 9.60 GHz / 0.031 m
|
| Polarization(s) |
L band: VV, HH, HV; X band: VV
|
| Incidence angle(s) |
L band: 22.0° X band: 21.2°
|
| Calibration |
Preview images:linear power, gray scale individually optimized for each
channel
Full images: calibrated absolute NRCS
|
| Date/Time |
April 11, 1994 / 21:31 |
| Area |
Galapagos Islands III, data take 40.05 |
| Coordinates |
Image center: L band: 1°30.2' S 90°28.2' W; X band: 1°27' S 90°29' W
Track direction at image center: L band:150.1°; X band: 150.1°
|
| Surface geometry |
L band: 50.750km*99.950km; X band: 38.700km*102.500km
|
| Other signatures seen in the image |
Oceanic internal waves, oceanic front |
