Image name
|
sirclcx9404160741
|
| Platform/Sensor |
SIR-C / X-SAR |
| Flight altitude/speed |
225 km / 7.8 km/s |
| Image partition |
3 fragments: L-VV, C-VV, X-VV
|
| Wavelength(s)/Frequency(ies)/Band(s) |
L and C band: 1.25 GHz / 0.24 m; X band: 9.60 GHz / 0.031 m |
| Polarization(s) |
L and C band: VV; X band: VV |
| Incidence angle(s) |
L and C band: 31.9°; X band: 29.5° |
| Calibration |
Full images: calibrated absolute NRCS
Preview images: linear power, gray scale individually optimized for each channel |
| Date/Time |
16.04.94 / 07:41 |
| Area |
Pommerian Bight, data take 112.02 |
| Coordinates |
Image center: L and C band: 55°2.3' N 16°36.4' E; X band: 55°4' N 16°22' E
Track direction at image center: L and C band: 103.5°; X band: 103.3° |
| Surface geometry |
L and C band: 95.700km*99.938km; X band: 23.600km*102.450km |
| Other signatures seen in the image |
Oceanic internal waves, oil pollution |
