Image name
|
sirclcx9404140931
|
| Platform/Sensor |
SIR-C / X-SAR |
| Flight altitude/speed |
225 km / 7.8 km/s |
| Image partition |
7 fragments: L-VV, L-HH, L-HV, C-VV, C-HH, C-HV, X-VV
|
| Wavelength(s)/Frequency(ies)/Band(s) |
L band: 1.25 GHz / 0.24 m; C band: 5.30 GHz / 0.057 m; X band: 9.60 GHz / 0.031 m |
| Polarization(s) |
L and C band: VV, HH, HV; X band: VV |
| Incidence angle(s) |
L and C band: 25.3°; X band: 23.9° |
| Calibration |
Full images: calibrated absolute NRCS
Preview images: linear power, gray scale individually optimized for each channel |
| Date/Time |
14.04.94 / 09:31 |
| Area |
Golfo de Thehuantepec / Mexico, data take 081.00 |
| Coordinates |
Image center: L and C band: 15°30.8' N 93°47.6' W; X band: 15°27' N93°53' W
Track direction at image center: L and C band: 31.8°; X band: 31.6° |
| Surface geometry |
L and C band: 26.950km*106.938km; X band: 28.800km*102.450km |
| Other signatures seen in the image |
Oceanic internal waves |
